Flipsky Brushless Motor 7070 4300W Waterproof Underwater Thruster electric boat thruster for ROV RC Boat /Jet boards /Outboard motor / Drive boat jet
Regular price
$340.00
Remark:R&D engineers recommend the glue of the motor bottom bracket be used 24 hours after pasting to avoid debonding before the glue dries.
7070 motor parameters
- Motor :7070/110KV
- Waterproof grade :IP58
- Guard material :ABS
- Fixing bracket:6061 aluminum alloy
- Propeller: 1 pcs propeller 3.8 inches
- Voltage range 6-20s (25.4-84v)
- Rated power 2200w
- Maximum power: 4300W
Battery box parameters
- Battery outer box size: 371*269*186mm
- Waterproof grade: IP67
- Battery box material: ABS
- Voltage:50.4V
- Cell specifications: Molicel P42A 27100
- Battery capacity: 12S 4P 16.8AH/846.72WH/16800mah.
- Environment: (-20 degrees Celsius + 50 degrees Celsius)
- Charger: 50.4V 5.5A
- Charging time: about 2.6 hours
ESC
- ESC model:75100 prov2.0
- Maximum discharge current: Maximum continuous 100A
- Voltage Range: 6-20s (25.2*84v)
- Heat dissipation method: water cooling (water pipe outer diameter 8MM, inner diameter 3MM)
- Support control protocols ppm, uart, adc, nrf, pas
Remote control
- remote control:VX3 Pro
- Control mode :UART
- Remote control distance: no interference, 25 meters in a straight line
- Waterproof grade:IP67
- There are 3 adjustable gears (L/M/H)
- Functions: Cruise control, GPS speed display, infinite throttle
Spec:
- Paddle board length, width and height Size: 320*110*20cm
- Safe load: 100KG
- Hull material: environmentally PVC
- Product Category: Inflatable Paddle Board
Inflatable Fishing Boat With Electric Motor Size：
Motor 7070 Thruster Drawing：
