flipsky_esc_tool  software and manual download link

Specs:

• Firmware: V1.0, supporting update via Flipsky ESC Tool
• Voltage: 14-84V(safe for 4-20S)
• Continuous current: 50V/60A; 75V/50A; 84V/40A (Values depend on the mounting, ambient
• temperature and air/water circulation around the device!); Peak Current: 250A
• Communication Ports: USB, CAN, UART
• Input Signal Support: PPM, UART(compatible with FLIPSKY remote VX4 only), ADC
• BEC: 5V@1A
• Multiple Speed Gear levels: Low, Medium, High, Reverse
• Motor/power wire size: 12 AWG
• Programmable: Yes
• Regenerative Capacity: Yes
• Size: L110.5*W55*H30mm(Including Alu. Case)

Features:

• Adopting CPU AT32F403ARCT7 with the structure of ARM Cortex-M4 allows CPU clock speed
• 240MHz and the max PWM switching frequency 45KHz, which improves the motor RPM.
• Programmable via Flipsky ESC Tool to be compatible with multi-types of motor, different battery
• voltages and many control ways.
• Programmable via Flipsky VX4 remote(Firmware Version:VX4_V1.2)
• Supporting FOC with low working noise and smooth starting.
• Supporting Real-time data and fault alerts.
• Supporting adaptive variable PWM frequency control.
• Supporting sensor mode(HALL) and sensorless mode(IPDS, HFPI).
• Supporting control types: Current, Duty Cycle
• Protection functions: low and high voltage protection, over-current protection, temperature
• abnormally protection, mosfets over-temperature and over current protection, battery over
• discharge protecting, motor over-temperature protection.

Spec:

• Firmware supporting update via Flipsky ESC Tool
• Voltage: 14-84V(safe for 4-20S)
• Continuous current: 50V/60A; 75V/50A; 84V/40A (Values depend on the mounting, ambient
• temperature and air/water circulation around the device!); Peak Current: 250A
• Communication Ports: USB, CAN, UART
• Input Signal Support: PPM, UART(compatible with FLIPSKY remote VX4 only), ADC
• BEC: 5V@1A
• Multiple Speed Gear levels: Low, Medium, High, Reverse
• Motor/power wire size: 12 AWG
• Programmable: Yes
• Regenerative Capacity: Yes
• Size: L110.5*W55*H30mm(Including Alu. Case)
• Power Switch Button: Red

Features:

• Adopting CPU AT32F403ARCT7 with the structure of ARM Cortex-M4 allows CPU clock speed
• 240MHz and the max PWM switching frequency 45KHz, which improves the motor RPM.
• Programmable via Flipsky ESC Tool to be compatible with multi-types of motor, different battery
• voltages and many control ways.
• Programmable via Flipsky VX4 remote(Firmware Version:VX4_V1.2)
• Supporting FOC with low working noise and smooth starting.
• Supporting Real-time data and fault alerts.
• Supporting adaptive variable PWM frequency control.
• Supporting sensor mode(HALL) and sensorless mode(IPDS, HFPI).
• Supporting control types: Current, Duty Cycle
• Protection functions: low and high voltage protection, over-current protection, temperature
• abnormally protection, mosfets over-temperature and over current protection, battery over
• discharge protecting, motor over-temperature protection.

Application Fields:

Electric skateboard / Ebike / E-Scooter / Electric Motorc ycle / Robotics / FPV / RC Toys /Boat / Kayak etc
