Specifications:
- Firmware: Flipsky_75_450
- Firmware version: 7.00 (Support 7.00 or above)
- Voltage: 14-84V (Safe for 4-20S)
- Continuous Current: 50V/ 450A; 75V/ 350A (Values depend on the mounting, ambient temperature
and air/water circulation around the device)
- Peak Current: 1200A
- BEC:5V@1A
- Programmable via VESC_TOOL: Yes
- Max Erpm:150000
- Communication Ports: USB, CAN, UART, SPI, IIC
- Input Source Support: PPM, ADC, NRF, UART
- Phase Filter: YES
- Size: L285mm*W133mm*H63.5mm (with Water Cooling Enclosure)
- Motor/Power Wire: 6AWG (1pcs combine)
- Power Switch Button: 16mm Self-lock Button (Red light)
Features:
- Water-proof: IP68.
- CPU: SMT32F405 of Cortex-M4 with DSP function and frequency 168MHz.
- Support Modes: BLDC, FOC (sinusoidal).
- Supporting Sensorless mode.
- Support various control modes: Current/ Duty cycle/ Speed/ PID.
- Adjustable protection against: low/ high voltage protection, over current protection, MOSFET/ motor over temperature protection.
- Regenerative capacity: Yes.
- Support dual ports (using Bluetooth and port control simultaneously).
- Adapt water cooling aluminum enclosure for better heat dissipation and expand life span.
Wiring diagram:



Manual
https://cdn.shopify.com/s/files/1/0011/4039/1996/files/FSESC75450_-_20261105.pdf?v=1794973043
