Specs:

• Material:Nylon
• Diameter: ∅120mm
• Pitch: 96mm
• Suitable For Flipsky 65111 motor

Please use 5V/2A charger for VX1 Pro (Max. Input voltage of 6.5VDC for VX1 Pro). Do NOT use a charger with an output voltage more than 6.5V, otherwise the VX1 Pro remote controller may be damaged.

Features:

• Using 2.4G wireless module-E28-2G4M12S, low power consumption, strong anti-interference ability, long remote control distance
• Support 3 speed modes (high gear: red light; middle gear: yellow light; low gear: green light)
• Support cruise control mode
• Remote control and skateboard battery indicator light
• Comfort touch: ABS+Rubber painting surface
• Support reverse function
• Rechargeable Li-ion Battery (850mAh)
• Anti-slip wrist strap
• VX1 Remote comes with Receiver

Kindly Reminder !
1.Please carefully check following receiver connection diagram corresponding with different FSESC, wrong cable collection in reciver side will cause the receiver burned.

2. The variants (for VESC4/ for VESC6 / For Non VESC) only differenciate on reciver cables , the remote is the same one.

What are the differences between VX1 and VX1 pro?

Receiver Connection Diagram:

For PPM mode(or Non VESC )

For Dual FSESC4.20 Plus:

For Dual FSESC6.6:

Spec:

• Hardware: V2.2
• Max voltage: 12S (50.4V)
• Continuous Current: 60A , Max Current: 120A
• Burst current: 800A(theoretical current)
• Mosfets: NVMFS5C628NLs
• LED button diameter:12mm, cable length: 250mm
• PCB thickness:4 layers*3oz copper=12oz copper
• PCB size: 40mm*32m
• Wire:12AWG

Enhanced Features:

• High Side Switching -> Much safer to use with multiple ESCs and other devices.
• In-rush current limiting.
• RC delay network restricts inrush current to safe levels.
• dV/dt is ~100V/s (This is considered VERY slow for power electronics. Fast would be 50,000,000V/s). At 6,000 uF output capacitance, this is an inrush current of 600mA.
• Smart Power on/off
• Roll-to-start. Has 12 second blanking timer after turn off. Can still be turned on by switch during this period.
• Auto-turn-off. Will turn off automatically after 20 minutes. The output voltage must vary by at least 500mV within any three second interval to reset the turn-off timer.
• Support momentary push button. Hold for 0.3s to turn on, 1s to turn off. Holding it down will cycle it on then off.
• High power, 150A Continuous.
• Very low idle power draw, ~300uA, will last months on battery.

1.Preventing a small spark may cause explosions in some spark-sensitive areas.

2. Add copper bars for better heat dissipation and over-current flow.

3.Anodized aluminum Heatsink with lots of notches for better heat dissipation.

4.Add silicon glue to fix the LED button cable with the heat shrink.

Warnings:

• Do not peel off the heat shrink.There’s no screw to lock the heatsink and PCBA. Only the heat-transfer silicon pad is naturally sticky to heatsink and PCBA.
• No short circuit protection, DO NOT short circuit output!
• No reverse polarity protection. DO NOT plug in backwards.
• Recommended to keep output capacitance under 6,000 uF. Proper operation cannot be guaranteed at higher capacitances.
• Do not Hot-Swap. Try to make sure everything is off before connecting and removing. If need be, unplug from battery first, wait for ESCs to turn off, then unplug ESCs. Do the reverse for plugging in, plug in ESCs first before plugging the switch into the battery.
• Engineers have thoroughly tested prototypes; however, this is still a new design and a first production run, please exercise extreme caution (as one would normally do with any electric vehicle) when using this device.
• Do not attempt to reprogram the MCU unless otherwise advised. Doing so will void any warranty and also put the switch at great risk of failure.

 Wiring diagram：

Spec:

• Axle Diameter: 8/10mm

• Material: Aluminum Alloy

• Color: Black

The detail size of 63 Series motor mount(Axle Diameter:10mm),Suitable for 6354/6374/6384 motors

The detail size of 50 Series motor mount(Axle Diameter: 8MM):(Suitable for H5045/H5055/H5045/H6368 motors,not suitable for 5065 270KV motor )

Package included:

2pcs motor mount

Please use 5V/2A charger for VX1 (Max. Input voltage of 6.5VDC for VX1). Do NOT use a charger with an output voltage more than 6.5V, otherwise the VX1 remote controller may be damaged.

Features

• 2.4Ghz band width
• Support 3 speed modes
• Support cruise control mode
• Remote and E-skateboard power indication lights
• Support checking remote battery volume
• Comfort touch: ABS+Rubber painting surface
• Rechargeable Li-ion Battery
• Wrist strap
• VX1 Remote comes with Receiver

Function Show

Kindly Reminder !

1.Please carefully check following receiver connection diagram corresponding with different FSESC, wrong cable collection in reciver side will cause the receiver burned.

2. The variants (for VESC4/ for VESC6 / For Non VESC) only differenciate on reciver cables , the remote is the same one.

3. When you choose UART mode connection for VX1 remote receiver, pls do connection after your programming in VESC tool. Or else , it will influence programming. And In UART mode, there is no need to do adjust for remote.

Receiver Connection Diagram

For Single V4

For Dual FSESC4.20: Both hook up with bluetooth and remote receiver

For Single V6

For Dual FSESC6.6 Plus : both hook up with bluetooth and remote receiver

For PPM mode(or Non VESC )

Manual：VX1_Remote_VX1_product_manual_-20190316.pdf
