How to Upgrad the Flipsky FSESC V110 Series ESCs Firmwares to V6.06

How to Upgrad the Flipsky FSESC V110 Series ESCs Firmwares to V6.06

For Flipsky's high-voltage ESCs—the FSESC V110 series, some units are shipped with firmware version V6.05 from the factory. If you need to use the latest VESC Tool for V6.06 version, simply follow the steps below to refresh and upgrade the firmware.

Item

ESC: FSESC110100/ FSESC110200/ FSESC110300
Firmware bin files download links:
FSESC110100--https://drive.google.com/drive/folders/1DScud5cghDxam-McT8yQz8ufR9Qqh_83?usp=drive_link
FSESC110200--https://drive.google.com/drive/folders/1qyh-C4fx1BeR2JW4SBtM-BtXnietDUwv?usp=drive_link
FSESC110300--https://drive.google.com/drive/folders/1ayuZiGvRzA6rmThdTPmUJiiEcOa6kvcF?usp=drive_link

Firmware Upgrade

a. Connect the computer to the ESC via a USB cable

Wires connected to the Flipsky FSESC V110 ESC, displaying setup for firmware upgrade to version 6.06.

b. Click "Connect" to connect to the ESC. A pop-up window will appear, and then click "OK".
 (A pop-up window at this step indicates that the ESC's firmware version does not match the VESC Tool version, requiring a firmware reinstallation with the matching version.)

VESC Tool interface displaying options for Flipsky FSESC firmware configuration and motor setup.
Warning message in VESC Tool about updating to Flipsky FSESC firmware with configuration options displayed.

c. Click on "Firmware", then select "Custom File". Next, click the folder icon to the right of "Use" and choose the firmware file corresponding to your ESC model.

VESC Tool interface displaying the Flipsky FSESC firmware upload section for version 6.06 installation.
Firmware selection screen for Flipsky FSESC firmware update to version 6.06 featuring various file options.

d. Be sure to select the firmware labeled "no limits".

Selecting the Flipsky FSESC firmware file in the VESC Tool interface for firmware updates.

e. Click the write button, then click "Yes" on the pop-up window to begin downloading the firmware.

Warning dialog in VESC Tool for uploading Flipsky FSESC firmware version 6.06, with hardware version confirmation prompt.

f.  Once the firmware download is complete, a completion pop-up will appear, then click "OK".

Warning message about Flipsky FSESC firmware upload status and reboot instructions on computer screen.

Note: DO NOT cut off the power of ESC before the solid green LEDlights up. Or the firmware upgrade may be not successful and blocked.

Flipsky FSESC firmware update setup showing wires connected to an ESC with capacitors on a flat surface.

g. After the firmware download is finished, return to the main interface "Welcome & Wizards" and click "Connect" to reconnect to the ESC. You can then proceed with normal parameter adjustment.

VESC Tool interface for Flipsky FSESC firmware setup and configuration.

It now also supports firmware updates via mobile phone. For detailed instructions, please refer to the video.
https://www.youtube.com/watch?v=bZqraMSjNIs
